BR2736/BR9569

View installers & retailers Find another part

Brake Disc

Part number: BR9569

Specifications

  • Brake Disc TypeVented
  • Coated
  • Weight10
  • Outer Diameter338
  • Brake Disc Thickness32
  • Min. thickness29
  • Height68.4
  • Centering Diameter108
  • Pitch Circle Ø139.7
  • Num. of holes6
Download full size diagram for printing
